8134 060500, Belden Twisted Pair Data Cable, 4 Pairs, 0.08 mm², 8 Cores, 28 AWG, Screened, 152m, Chrome Sheath, Кабель

Belden Data Cable, 120Ω Characteristic Impedance, Beldfoil Insulation - 8134 060500

Hook up your electronic components in a jiffy with this 28AWG data cable from Belden. With only a 78ns/100m delay, it zips signals between devices in a flash for near-instant responses. To safeguard your setup against damage caused by power faults, the cable has a drain wire that redirects sudden surges away from downstream equipment. A 30V voltage rating makes this an ideal option for light-duty kit like handheld devices.

Features & Benefits

• Performs in demanding environments thanks to its wide -30°C to +80°C temperature range
• Tinned-copper conductor resists corrosion for reliable use in humid settings
• Durable PVC jacket withstands wear and tear to suit unfixed installation

Applications

• Telecommunications industry
• Robotic systems
• Manufacturing facilities

What is Beldfoil?

This cable comes with an overall Beldfoil shield, which is Belden's patented combination of aluminium and polyester. It effectively protects against EMI and RFI to ensure crystal-clear signal transmissions.

Standards

UL2919; NEC CM
