90142-0010, Molex, C-Grid III Female Connector Housing, 2.54mm Pitch, 10 Way, 2 Row, Корпус разъема

Molex C-Grid III Interconnection System Connector Housings

This range of Connector Housings feature a 2.54 mm pitch and form part of the C-Grid III interconnection system from Molex. This system offers post and receptacle interconnection, with design flexibility and modular components that provide a wide range of interconnection packaging alternatives within the electronic markets. Ideal for use with a wide range of commercial and consumer applications.

Features and Benefits

• 2.54 mm pitch
• 1 to 80 Circuits
• Dual and single row housing
• Black in colour
• Wire to board configurations and fittings
• Uniform locking system in place on all contacts
• Interchangeable housing styles

Molex Female Connector Housing, 10 Way, 2 Rows - C-Grid III Series - 90142-0010

Protect your wire-to-PCB (printed circuit board) connections with this connector housing from Molex. The housing is made of a polyphenylene oxide (PPO) material that provides good electrical insulation and is highly resistant to heat distortion, making it a reliable choice for demanding electrical applications. The material also protects the connection from weathering by keeping your wires shielded from moisture and dust.

Features & Benefits

• Wide operating temperature range of -55°C to +105°C for use in extreme industrial environments
• 10 contacts arranged in two rows to save space and keep connections organised
• Compact dimensions of 12.7 (length) x 7.72 (width) x 15.24mm (depth) for use on PCBs where space is limited
• Light weight of 0.72g to prevent additional bulk or strain on your equipment
• Compatible with Molex's C-Grid III series of connectors for ease of assembly

Applications

• Sound systems
• Automotive industry
• Office equipment

How do I connect cables to the housing?

The housing uses a locking system that makes it simple to insert your cables and install them securely. The contacts are fully polarised to prevent accidental mismating or damage to the cable during installation.

Standards

DIN 41651; HE13/14

2.54mm Molex C-Grid III Range

Datasheet

Line Drawing
