NC6FP1, Neutrik Panel Mount XLR Connector, Female, 50 V, 6 Way, Silver over Nickel Plating, Разъем

Neutrik XLR Connector

The Neutrik P series female XLR connector has 6-pole with silver over Nickle-plating. It has a current rating of 7.5A with a voltage rating of 50V. It is the smallest available traditional style metal panel mount connector with large solder cups for ease hard wiring. Their construction ensures reliable connection for both power and low-level signal circuitry.
Warning:
Not to be used as mains connectors.

Features and Benefits

Compatible with Cannon XLB2*31, XLB2*32
Connector/Cable assembly is straightforward employing a minimal number of parts
Front mount only
One-piece version insert is not removable from shell
Parts are polarised and securely fitted thereby eliminating connector noise
Short female receptacle
Housing material is zinc
Operating temperature ranging between -30°C and 80°C

Certifications

IEC 61076-2-103
IEC 68-2-20
IP40 rated
UL 94 HB approved

AUDIO TYPE XLR AXR FINITION NOIRE

Technical Drawing
