EMC 1500, Lascar, 5 Digit, LCD, Counter, 27 V dc, Счетчик часов

Lascar Hour Counter

The Lascar digital hour counter is a 5-digit, panel mount device with an LCD for recording elapsed time. It has a supply voltage rating ranging between 5VDC and 27VDC with 1.5mA current rating. The module features 9999.9 and 99999 hour ranging, resulting in 1/10 hour and 1-hour resolution respectively. It features leading zero blankings, trip/total indication and hourly pulse output. This counter displays in hours (HHHHHH:HH). The meter can be panel mounted by drilling a 5.5mm (0.22in) hole. The connection to the meter is established through a set of wires.

Features and Benefits

Single hole mounting hour meter
Trip and total measurement
Ideal for tracking machine hours
Voltage sense input and 100 hour pulse output
No back-up power required
Splash proof protection
Screw terminal connection
Operation temperature ranging between 0°C and 50°C

Applications

Precision instrumentation systems
Power supply monitoring
Hand held instruments
Automotive projects

Certifications

IP67 rated
NEMA 4X (with rubber seal installed)
