2744458, Phoenix Contact ACT20X Series Signal Conditioner, RS-232 Input, TTY Output, 24V ac/dc Supply

Phoenix Contact Signal Conditioner, PA Housing, Modbus Signal - PSM-ME-RS232/TTY-P - 2744458

Need to bridge the gap between your new system and legacy network? This signal conditioner from Phoenix Contact does the trick. It converts from RS-232 to TTY to bring older equipment using 20mA loop signals back into the fold. Thanks to its bidirectional conversion design, data flows both ways to boost your equipment's capabilities. With TTY in your industrial or automation setup, you can enjoy error-free transmissions of up to 1000m on twisted pair cables at 19.2kbps speeds.
To maximise uptime, a suppressor diode protects your connection from sudden surges up to 2kV. With its mean time between failures of 1989 years, you can rely on this device for non-stop action. Plus, it only consumes 1.8W of power, making it an energy-efficient addition to your infrastructure. Supply this product with 24V AC or DC to get it up and running.

Features & Benefits

• Wide operating temperature range between 0°C and +55°C means it's ideal for demanding applications
• IP20 rating indicates it's safe to touch
• Mounts directly on a standard DIN rail for easy assembly
• Can accommodate cables sized 24 to 13AWG, so it's versatile
• Slim dimensions of 22.5 (W) x 99 (L) x 118.6mm (D) take up minimal space in your control cabinet

Datasheet

Line Drawing - 2744458

Instruction Sheet - 2744458
