RCF 630, Acim Jouanin Formable Coil Heater, 1.15m, 630 W, 230 V ac, Керамический нагревательный элемент

Cold-formed heating resistors

Formable heating resistors can take on any shape after forming and may therefore be used to replace faulty specific resistors, or in a normal capacity on injection nozzles, sheaths and cylindrical parts.
The internal bend radius is 8 mm for the round sleeve and 7 mm for the square section.
The resistor must be formed to be slightly smaller than the part that will be heated, to ensure good contact.
The heating length must be determined according to the part to be heated.
A formed CFR may not be reformed.

Strip Heating Elements

Note

To obtain optimum performance from these products, it is advised that temperature sensing and control elements be used with them

Warning

For reasons of safety the heater block and/or heater sheath must be bonded to earth

Approvals

UL Recognised; CSA Certified
