ACA-20PC-2-AC1-RL-C, Murata Power Solutions Digital Ammeter AC, 21.3mm x 33.9mm, Амперметр

Murata Power Solutions Digital Ammeter

The Murata Power Solutions digital Ammeter is the first digital AC device to incorporate on-board current transformers (CT’s). Absolutely no external components, such as expensive low-value shunts or 5A "donut" CT’s, are required. This easy to use device has a full-scale current of 19.99A and a power supply current of 50mA.

Features and Benefits

AC current
Bright red LED displays
Cut-out height is 21.3mm
Cut-out width is 33.9mm
Number of digits are 3.5
Operating temperature ranges between 0°C and 60°C
Power supply voltage ranges between 85VAC and 264VAC
Precision A/D converters
Scaling/interface circuitry

Certifications

ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007

Datasheet
