3031238, Phoenix Contact ST 2.5-PE Series Green/Yellow DIN Rail Terminal Block, 0.08 → 4mm², Single-Level, Spring Clamp

Phoenix Contact DIN Rail Terminal Block, 2 Contacts, 52A Current Rating - ST 2,5-PE - 3031238

Keep your panel wiring well-grounded from electric hazards using this DIN rail terminal block from Phoenix Contact. It's a single-level unit with two connections to accommodate a dual cable connection. As it accommodates wires that range in size from 28 to 12AWG, it gives you flexibility in your wiring. You can attach conductors by simply pushing them in, thanks to the simple spring clamp termination method. An open side panel gives you free rein to adjust the wires without removing the block from the rail.
As it has a current rating of 52A, this block can withstand the rigours of heavy-duty equipment like railway and process control systems. Mount it in a jiffy by snapping it to an NS 35/7.5 or NS35/15 rail. Its green/yellow housing complies with industry-standard colouring, so you can immediately identify it as a ground terminal block in a busy control panel.

Features & Benefits

• Rated surge voltage of 8kV to withstand overcurrent
• Maximum power dissipation of 0.77W for energy efficiency
• ATEX-certified for safe use in hazardous environments
• Safe performance in harsh settings with an operating temperature range between -60°C and +105°C
• Resists mechanical shock to withstand demanding operations

Datasheet

Instruction Sheet - 3031238
