LC1D12B7, Schneider Electric LC1D Series Contactor, 24 V ac Coil, 3-Pole, 12 A, 5.5 kW, 3NO, 690 V ac, Контактор

Schneider Electric LC1D TeSys D Contactors

TeSys D Contactors from Schneider Electric combine long mechanical and electrical life to offer a high reliable contactor. The range has been designed for integration in control systems and can be used to create motor starters for any type of application. The TeSys D contactors offer quick simple setup while maintaining compliance with international standards.

Features and Benefits

• Built-in auxiliary contacts for added switching capability
• Screw connections: IP20 finger-safe terminals with both North American and International terminal markings
• Can be panel mounted with screws or DIN Rail mounted
• Bidirectional peak limiting diode suppressor to protect the coil
• Easily installed accessories
• Flexible control circuit to suit a wide range of applications

What does the utilisation category AC1 and AC3 mean for the TeSys contactors?

Contactor utilisation categories define the current making and breaking values, based on the type of load to be controlled and the operating cycle conditions.

• AC-1: This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution.


• AC-3: This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units.

What accessories are available?

• Auxiliary contact blocks with serrated wiping action
• Front mount dust tight auxiliary contact blocks
• Pneumatic time delay blocks
• Transient voltage surge suppressors
• Interface modules and electronic timers
• Mechanical latching blocks

Is the TeSys D range a double break pole type contactor?

Yes the Tesys D range uses linear translation movement that provides double breaking of the poles.

Schneider Electric Contactor, Screw Terminals, 12A Contact Current Rating - TeSys DSeries - LC1D12B7

When your electric motor's at risk of spinning out of control, use this three-pole contactor from Schneider Electric's TeSys D range to get it in hand. Designed and tested for AC-1, AC-3 and AC-4 utilisation categories, the unit can handle both inductive and resistive loads. It can also start and stop electric motors at a normal or rapid pace, making it a versatile addition to your system. This industrious device operates at a maximum rate of 3,600 cycles per hour in temperatures up to +60°C, so you can be sure it'll keep up in tough environments.

Features & Benefits

• Finger and back-of-hand proof for safety during installation and servicing
• Mechanical lifespan of 15,000,000 cycles keeps maintenance low
• Front cover adds extra protection in harsh conditions
• Mirror type of auxiliary contact for signalling applications

Applications

• Conveyors
• Hoists
• HVAC equipment
• Compressors

Can I add more auxiliary contacts to this contactor?

Yes, you can add a TeSys D auxiliary contact block from the LAD series. This includes the 2NO and 4NO versions as well as LADT0 and LADT4 time-delay blocks, so you have plenty of choices to suit your setup.

Approvals

LROS (Lloyds register of shipping), CSA, UL, GOST, DNV, CCC, GL, BV, RINA, UKCA.

Standards

CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 508, IEC 60335-1.

UL E164862

CSA 43364
