SP 200, Lascar Digital Voltmeter DC, LCD Display 3.5-Digits ±1 %, Вольтметр

Splash-Proof Ultra Low Profile LCD Voltmeter

The SP 200 has a 200V d.c. measurement range with auto-zero and auto-polarity. The device features a negative rail generator which enables the meter to measure a signal referenced to its own power supply GND.

LED backlighting ensures excellent readability under low light conditions. The module is easily fitted into the panel, using the fixing clip provided. The modules low cost means it will suit high and low volume application. The design of the panel meter's housing ensures splash proofing using the supplied seal.

Features and Benefits

9.75mm digit height
200mV d.c. full scale reading
350μA @ +5v D.C. Power Supply
Auto-zero and auto-polarity
Programmable Decimal Points
LED backlighting
Low Battery Warning
Splash Proof

Supplied with
type":"Supplied with",

rubber sealing gasket.

LCD 5.5 to 18 mm Digit Height
