RS PRO Hose Pipe, PVC, 6mm ID, 11mm OD, Black, 30m, Шланг

Extra Flexible Antistatic Air Hose

Designed specifically for electro-static sensitive environments, Anti-Static Hose is the effective hosing solution for areas with potentially damaging static build-up. Widely used by the electronics industry and developed in collaboration with a leading manufacturer of pneumatic tools

Features and Benefits

• Effective anti-static properties to reduce the risk of electro-static damage
• Highly flexible, reinforced PVC hose
• Typical electrical resistance recorded at between (3 x 103 Ω per metre (minimum) and 1 x 106 Ω per metre (maximum)
• Low toxic liner suitable for food use
• Cadmium and silicone-free
• Resistant to a wide range of chemicals
• Abrasion-resistant
• Specially selected high tensile polyester fibres used at the optimum braid angle of 54° 44′(54.73°) creates an effective and balanced pressure hose
• Service temperature -15°C to + 60°C
• 4:1 safety factor

Product Application Information

• Widely used by the electronics industry – especially computers
• Pneumatic tools and equipment in electro-static sensitive areas

Note

The connection device must be earthed/grounded
Working Pressure is at +20°C

Standards

BS6066 1981 (1986) and ISO 5774 1980

Approvals

BS2050 1978(1998) 4.12

PVC Industrial Hoses - Coloured

A range of industrial hoses made from Cadmium free materials. Offering excellent abrasion resistance and good flexibility, they are Silicone free ,with a service temperature of -15°C to +60°C.

RS Pro Datasheet
