LC1D150P7, Schneider Electric LC1D Series Contactor, 230 V ac Coil, 3-Pole, 150 A, 80 kW, 3NO, 1 kV ac, Контактор

Schneider Electric Contactor, AC Controlled, 80kW Power Rating - TeSys D Series - LC1D150P7

Manage the electrical circuit in your system reliably with this AC-controlled contactor from Schneider Electric's TeSys D range. The special TH protective treatment prevents corrosion from condensation, making this an ideal option for use in moist and humid environments. Thanks to an operating temperature range of -40°C to +60°C, you can be sure this unit will perform reliably in demanding industrial conditions. As it supports up to 1200 cycles per hour, you can safely turn your electrical system off and on as needed.

Features & Benefits

• IP20 rating indicates the unit is touch-proof and protected against small objects over 12mm
• Fire-resistant up to +850°C to minimise electrical fire risk
• Bidirectional peak-limiting diode suppressor protects the coil from damage caused by electrical faults
• Screw termination method for simple installation and secure connections that can withstand vibration
• Dimensions of 158 (L) x 120 (W) x 132mm (D) for installation in busy setups

Applications

• Production lines
• Warehousing and distribution facilities
• Automotive industry

How do I mount this contactor?

Depending on your system's layout, you can either clip the unit onto a standard DIN rail or secure it to a panel with screws.

Approvals

LROS (Lloyds register of shipping), CSA, UL, GOST, DNV, CCC, GL, BV, RINA, UKCA.

Standards

CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 508

UL E164862

CSA 43364
