RS PRO 2-Port RJ45 T-Adapter, Cat5, Unshielded

Cat. 5 T Adapter

Cat. 5
Available shielded or unshielded
Connection cable 150 mm, strain relief, RJ45 plug with locking lever protection
Halogen-free plastic housing, light grey (RAL 7035)
Outputs are labelled using inserted colour symbols for data or telephone
Labelling field with transparent window
Wiring diagram label on the underside
For splitting an 8-core RJ45 output for two different applications

Performance features

Note

Use one T adapter on patch panel and one on boxes

Standards

Cat. 5 in accordance with ISO/IEC 11801

RS PRO Cat5 RJ45 T-Adapter, 2 Port, Unshielded, 150 mm Extension Length

This RS PRO T-adapter converts Cat5 cables to an RJ45 connector for a reliable, electromagnetically insulated Ethernet connection. It's frequently used to link computers to Ethernet-based local area networks (LAN).


The adapter features two ports, allowing you to connect two cables simultaneously. Its 150 mm extension length lets you fit the adapter around office desks and other tight locations.


This unit comes with a three-year RS PRO warranty to guarantee high-quality performance. It also complies with the Restriction of Hazardous Substances (RoHS) directive, meaning it contains only trace levels of any harmful materials.

Features and Benefits

• Extension length of 150 mm


• RJ45 interface type


• Cat5 LAN category


• Two ports


• Unshielded type


• T-Adapter type


• Straight-through wiring configuration

RS Pro Datasheet
