IK9094.11 AC/DC24V 0-150°C, Dold Temperature Monitoring Relay, SPDT, DIN Rail, Реле контроля

IK 9094 Temperature monitor for PT100

The IK 9094.11 AC/DC24V 0 to 150°C is a Temperature Monitoring Relay with detection sensor of in-circuit broken wire. It features LED indicator for operation and state of output relay.Perfect for monitoring for example, motors, ball bearings.

This relay has no galvanic separation between measuring and auxiliary circuit. The hysteresis and latching functions are full programmable via X1 terminal.

Operating temperature: \t\tFrom -20°C to 60°C

Mounting Type:\t\tDIN Rail

Housing/terminal protection class:\tIP40/IP20

Dimensions:\t\t\t17.5 x 90 x 59 mm

Features & Benefits

Standards

IEC 255, VDE 0435

Datasheet
