KS40-102-0000D-000, P.M.A KS40 PID Temperature Controller, 96 x 48mm, 3 Output, 90 → 250 V ac Supply Voltage, Регулятор температуры

P.M.A Temperature Controller

The P.M.A KS40 series temperature controller has a supply voltage rating ranging from 90VAC to 250VAC. This high precision controller has a width of 48mm and a height of 96mm(1/8DIN). It has three process outputs that are two relays and one analogue or logic output. The universal output can be used for operating a solid-state relay, a continuous current/voltage output or to energize a 2-wire transmitter. The controller intended for universal, precise and cost-effective control tasks in all branches of industry. For this, the unit provides simple 2-point (ON/OFF) control, continuous PID control, or 3-point stepping control. The process value signal is connected via a universal input. The supplementary analogue input can be used for heating current measurement or as an external setpoint input.

Features and Benefits

Automatic/manual key
BluePort front interface and blue control software
Extended limit signalling function with latch
It has flat pin connector
Maintenance manager and error list
Monitoring of heating current and input circuit
Timer and programmer

Applications

Burners and boilers
Furnaces and ovens
Plastics processing and driers

Certifications

Front panel IP65 rated
Housing IP20 rated
Terminals IP00 rated
Type tested to EN 14597 (replaces DIN 3440)
UL approved
