3RT1016-2AF02, Siemens 3RT1 Series Contactor, 110 V ac Coil, 3-Pole, 9 A, 4 kW, 3NO, 400 V ac

4192591
Номер производителя: 3RT1016-2AF02Производитель: Siemens
Цена за шт.
11762.40 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Contactors - 3RT Range

Size 00
Dimensions; H57.5mm x W45mm x D72.5mm

Note

Most of the Sirius 3R components are available with cage clamp connections. For the size S00 products, with rating up to 5.5kW, this includes both power and control circuit connections. For higher rated products cage clamp is available for the control wiring connections such as operating coils and auxiliary contacts.

Warning

This product is in obsolescence mode and is due for discontinuation by the manufacturer. We recommend that you review the alternative highlighted by the manufacturer. Alternatively, refer to the cross reference list in the Technical Reference section which highlights the upgrade path for your current generation of products.

Siemens SIRIUS Cage Clamp Technology

As an alternative to screw connections a large number of Siemens low voltage components are also available with cage clamp connections.,Solid, stranded and finely stranded conductors, with or without end sleeves, can be connected, where two conductors can be clamped independent of one another at each terminal.,Inserting a flat bladed screwdriver opens the terminal; the conductor is then introduced and securely clamped following the removal of the screwdriver. The chromium-nickel spring steel of the cage clamp terminal guarantees corrosion resistant contact of the conductors.

Advantages

Time saving: the connection can be made quickly without having to press on end sleeves
Reliability: the terminal connection is resistant to shock and vibration
Vertical Mounting
Reduced maintenance: the cage clamp system means that the checking of screw connections following transportation is unnecessary

Техническая спецификация
pdfSiemens Sirius Migration
pdfSirius: Migrating From Classic to Innovation
Глубина:
73мм
Диапазон:
SIRIUS
Длина:
60мм
Катушка напряжение:
110 В перем. тока
Количество вспомогательных контактов:
1
Количество полюсов:
3
Мощность номинальная:
4 кВт
Номинальное напряжение контакта:
400 В перем. тока
Номинальный ток контакта:
9 A
Нормальное состояние конфигурации:
3NO
Рабочая температура - максимальная:
+60°C
Рабочая температура - минимальная:
-25°C
Серия:
3RT1
Тип клеммы:
Cage Clamp
Ширина:
45мм
