RS PRO Brass Earth Clamp, Заземляющий зажим

RS PRO Earth Clamp Brass, 3 to 35 mm² Wire Range

Earth your metal installations easily with the RS PRO earth clamp. Also known as a grounding strap, this component provides an outlet for excess current if there's a fault in the system, allowing it to flow into the earth for safety. It's used in both domestic and commercial settings.

Designed to be fitted easily, you won't need to drill or dismantle your equipment. The clamp provides a permanent earth connection, but the wire is still removable. It's suitable for flange thicknesses ranging from 3 mm² to 12.5 mm². The integral metal clamp accepts conductors up to 35 mm².

This component helps installations to meet section 601-04-02 of the BS7671, IEE regulations for safety and quality. Each brass clamp is supplied with metal safety labels. It's RoHS compliant for minimal use of hazardous materials. For shear bolt connections, an 8 mm ratchet tool, stock no. 426-3148, is available.

Features and Benefits

• Brass earth clamp
• Helps installations to meet section 601-04-02 of the BS7671, IEE regulations for safety and quality
• Minimum wire size of 3 mm²
• Maximum wire size of 35 mm²
• RoHS compliant for minimal hazardous materials
• Handled and packed in conditions that meet ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 electrostatic control standards

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Supplied with
