208.100.55, Werma EM 208 Series Red Flashing Beacon, 24 V dc, Panel Mount, Xenon Bulb, IP65, Маячок

Flashing Installation - Series 208

Flashing xenon units
0.75 Hz frequency and 1 Ws flash energy
57mm diameter
Panel cut out M22 (22.5 mm) with 6.3 mm Faston connections

WERMA Beacon, Flashing Light Effect, Red Lens Colour - EM 208 Series - 208.100.55

This beacon from WERMA provides a visual alert of an emergency in busy work environments. Its xenon bulb produces a flashing red light with 360° visibility for an effective signal. Its housing is made from tough PA fibreglass that's highly resistant to impact for durability in heavy-duty environments. This unit has a lifespan of 4,000,000 flashes for long-term performance.

Features & Benefits

• Wide operating temperature range between -20°C and +50°C for use in challenging settings
• Compact dimensions of 69 (height) x 57mm (diameter) to take up minimal space
• IP65 rating means it's dust-tight and protected against low-pressure water jets

Applications

• Packaging machinery
• Hospitals
• Marine industry

How do I mount this beacon?

This beacon is designed to fit into a standard 22.5mm panel cutout for ease of installation. Thanks to the built-in Faston terminals, you can quickly connect it to your circuit without the need for complex tools.
