643.300.55, Werma 643 Series Yellow Flashing Effect Beacon Unit, 24 V dc, Xenon Bulb, DC, IP65

Stacking Signal Tower - KombiSIGN 71, 70 mm, IP65

The WERMA KombiSIGN 71 modular stacking signal tower is an ideal solution to the increasing requirement for safety, machine productivity and reduced downtime. The modular design of these stacking towers enables quick and easy installation. Each KombiSIGN module is equipped with a bayonet fixing with integral contact system. Simply align the corresponding white marks and gently twist to lock them in place.

Features and Benefits

• Suitable for machine and manual Andon indication
• Modular system allows a completely free combination of optical and audible signal elements
• Mechanical and electrical connection of the elements in the space of seconds using a bayonet connection system
• Completely safe element changes (contact-voltage proof) without the need for tools
• Protection rating IP65 for use in extreme conditions
• Up to 5 elements can be mounted on a terminal base
• Flexible combination of optical and audible elements
• Optical isolation due to O-ring seal stopping illumination of adjacent element
• Operating voltage for the continuous incandescent element is dependant on bulb fitted
• LED EVS elements have an extremely bright, random sequence of light to immediately grab attention
• Ultra-bright elements are up to 20 times brighter than conventional LED beacons. Intelligent electronics ensure operation at maximum brightness
• Vocal element plays customer specific audio files in mp3 format (sounds, alarms, music or spoken word)
• Optional self adjusting siren automatically adjusts output between 80 & 100 dB depending on ambient sound levels
• AS-Interface element can be easily connected to the networking system which considerably reduces complex wiring
• Improved connection with cage clamp technology
• Operating temperature range is -20 to +50 °C
• Polyamide body with polycarbonate lenses, 70 mm diameter

Permanent Multi-colour LED Light Element

• Seven colours in one beacon
• Different colours can be triggered via the pins in the terminal element
• Positive and negative control logic
• The three basic colours (red/yellow/green) can be triggered using only two PLC outputs
• High light intensity

Note

Lamps are not supplied and must be purchased separately. Not compatible with KombiSIGN 70.

Approvals

UL listed, CSA, VDE

WERMA Beacon Unit, 74g Weight, 70mm Base Diameter - KombiSIGN 71 Series - 643.300.55

Need to alert personnel to the status of your machinery? This beacon unit from WERMA is just the thing. It has an internal xenon bulb that emits a bright yellow flashing light for easy visibility. Thanks to the wide operating temperature range of -20°C to +50°C, it can take the heat in demanding industrial conditions. The tough PC lens resists UV rays, making it a safe choice for outdoor use.

Features & Benefits

• Bayonet connection system enables tool-free mounting
• Electrical protection class II assures you it's insulated, shielding you from shocks
• IP65 rating indicates protection from dust and low-pressure water jets

Applications

• Warehousing and logistics
• Power plants
• Mining and quarrying equipment

How long does this beacon last?

As this beacon has a minimum optical service life of four million flashes, you can expect it to last for the long haul.
