TRACOPOWER Switching Power Supply, TXL 035-1515D, ±15V dc, 1.5 A, 2.4 A, 35W, Dual Output, 88 → 264V ac Input, Источник питания

Traco Power Switching Power Supply, Dual Output, 36W Power Rating - TXL Series - TXL 035-1515D

Get your inputs and outputs on the same wavelength with this switching power supply from Traco Power. It accepts a universal supply voltage ranging from 88 to 264V AC and 125 to 375V DC, so it's a versatile option. In return, you get a smooth ±15V DC output. Designed for chassis mounting and featuring screw terminal block connections, it’s easy to install. A low-profile metal case gives added strength for long-lasting performance. To ensure you're not blindsided by sudden surges, there's built-in short-circuit protection that puts a stop to damage caused by power faults.

Features & Benefits

• 84% efficiency to save energy in compliance with European EMC standards as well as the low voltage directive (LVD)
• Operates reliably in temperatures ranging from -20°C to +70°C
• Withstands humidity levels between 20 and 90% for smooth functioning in damp settings

Applications

• Circuit monitoring
• Consumer electronics
• Mechanical workshops

What size is this switching power supply?

With dimensions of 99 (L) x 35 (W) x 82mm (D), this compact unit fits neatly inside electrical equipment.

Does this unit provide overvoltage protection?

Yes, overvoltage protection keeps the unit safe even when voltage is raised to a maximum level of 140%.

TXL 035_050_060 CB Series Test Certificate

TXL UL Certificate of Compliance

TXL 035-1515D Datasheet

Industrial Power Solutions Catalogue

Selection Guide

Application Note - TXL Series

Instruction Sheet - TXL 035 - 1515D
