REC3-2412DRW/H4/A, Recom REC3 DC-DC Converter, ±12V dc/ ±125mA Output, 18 → 36 V dc Input, 3W, Through Hole, +85°C Max Temp -40°C, Преобразователь

RECOM DC-DC Converter, 18 to 36V DC Input, 3W Power Rating - REC3 Series - REC3-2412DRW/H4/A

Step down a 24V DC industrial power supply with this DC-DC converter from RECOM. It provides a stable output of 12V DC and has a high power rating of 3W to handle more demanding applications. For safety, the device provides continuous short-circuit protection to minimise the risk of input power faults causing damage to your equipment. High isolation of 4kV DC makes it suitable to use in medical environments, as it protects people in direct contact with equipment from shocks. As it's self-extinguishing, you can rest assured the unit is unlikely to contribute to a fire.

Features & Benefits

• Convenient auto restart function, so no need for manual intervention
• Plastic housing is non-corroding, so suitable for humid operating conditions
• Wide operating temperature range of -40°C to +85°C for compatibility with demanding environments
• Able to operate under no-load conditions without any damage

Applications

• Instrumentation and test equipment
• Industrial control
• Telecommunication networks
• Medical equipment

Is this a regulated converter?

Yes, this DC-DC converter is regulated, so it offers tight control over output voltages regardless of how much its operating conditions vary. This means you can rely on it for a consistent voltage supply.

Test Report ETS-060065

Datasheet
