Z 141.003, Baumer Female 12 way M23 to Unterminated Sensor Actuator Cable, 2m, Кабельная сборка

Universal coders with hollow axis, Ø 58, type GI333

The coder can be powered by a wide supply range of between 4.75 and 30 Vdc.
Universal output stage, compatible with Totem pole, NPN or PNP and RS422 or TTL line transmitter.
Resolution up to 5000 pulses / turn.
A, B, Top zero and complemented output signals.
Hollow axis coders for direct mounting onto the end of a motor shaft, bored hole Ø 12 mm H7.
Concentric tightening using ring, rotation locking using rod and stopper supplied with the coder.
Anti-rotation spring available as a option.
Connection via supplied radial connector.
Shielded cable connected to the connector available as an option.
Application: robotics, metal or wood working, paper, textiles, packaging machinery, etc.

Kubler

Push pull interface with inverted signals
Short circuit protection
Age and temperature compensation

Z 141 Accessories Data Sheet
