2CDS251001R0325 - S201B32, ABB System Pro M Compact S200 MCB, 1P, 32A Curve B, 253V AC, 72V DC, 6 kA Breaking Capacity

ABB MCB, Type-B Tripping Characteristics, DIN Rail Mounting - S200 Series - 2CDS251001R0325-S201B32

When you need to protect circuits in small spaces, put this miniature circuit breaker from ABB to work. It shuts down power in a flash during a short circuit or overcurrent event, preventing damage to components downstream. Type-B tripping characteristics mean the MCB trips when it receives a current three to five times its 32A rating, making it fit to handle small surges in kit like commercial and residential lighting systems.

Features & Benefits

• Wide operating temperature range between -25°C and +55°C means it performs in challenging conditions
• Insulated thermoplastic housing protects against electric shocks and shrugs off impact damage
• Versatile option that handles both AC and DC circuits
• Simple, tool-free installation directly to your DIN rail
• Colour-coded indicators show you the contact position at a glance

Applications

• Engineering workshops
• Factory floors
• Storage facilities

How many poles does this MCB have?

This straightforward device has a single pole, making it suitable for monitoring one circuit at a time.

How much does the unit weigh?

It weighs in at just 125g, so it won't strain your DIN rail.

ABB System Pro M Single & Double Pole MCB's

Note

The Classic & System pro M product cannot be intermixed and do not share common accessories. System pro M products can only be fitted to new style Protecta distribution boards,see typically stock no. 539-1553.

Datasheet - 2CDS251001R0325 - S201B32

Datasheet - 2CDS251001R0325 - S201B32

Catalogue - Miniature Circuit-Breakers

Product Environmental Profile
