7906230000, Weidmuller SAK Series Non-Fused Terminal Block, 3-Way, 41A, 22 → 10 AWG Wire, Screw Termination, Клеммная колодка

Weidmüller Terminal Block

Terminal blocks moulded in high grade melamine. Each termination consists of a nickel plated brass yoke, two zinc plated steel screws and two stainless steel leaf springs. The leaf springs protect conductors when the screw termination is tightened.

Features and Benefits

• Multi-pin terminal strip
• Screw connection
• Each through termination accepts both stranded and solid conductors 0.5 mm² to 6 mm²
• Recommended insulation stripping length 8 mm

Group and Category

II 2 GD EEx e II

Certificate No.

SIRA01 ATEX3249U

Approvals

UL listed, CSA certified

EMD

SIRA 01ATEX3249U

Multipole Terminal Strips Catalogue Extract
