0034504, Lapp Multicore Data Cable, 0.34 mm², 4 Cores, 22 AWG, Screened, 100m, Grey Sheath, Кабель

LAPP Control Cable, 4 Cores, 22AWG - UNITRONIC Series - 0034504

Use this control cable from LAPP to send signals to and from computers or electronic control devices. Its wires are DIN colour-coded, which helps increase safety by allowing easy identification of each wire's function. The cable's PVC core insulation assists in preventing electrical leakage and provides protection to the wires for increased durability and a long service life. Integrated screening reduces electrical interference, which helps to improve the stability of the signal transmission.

Features & Benefits

• 100m length is simple to cut to the desired length for your application
• Flame-retardant to prevent the spread of a workplace fire
• 0.34mm² cross-sectional area, for use in areas where space is limited
• Wide operating temperature range between -40°C and +80°C when fixed and -5°C to +70°C with occasional flexing, for safe industrial use

Applications

• Food production
• Robotics machinery
• Process control
• Communications, signal and control systems
• Signal and broadcast environments

Is this cable flexible?

Yes. When fixed in position, the cable has a bend radius of 6 times its diameter. When the cable is permitted occasional flexing, the bend radius increases to 15 times the diameter, so you can install it around corners or in confined areas without risk of damage.
