276845 DILM12-10(24VDC), Eaton Contactor, 24 V dc Coil, 3-Pole, 12 A, 5.5 kW, 3NO, 400 V ac, Контактор

Eaton Contactor, 3 Poles, 12A Contact Current Rating - DILM Series - 276845 DILM12-10(24VDC)

Take power over your electrical application with this contactor from Eaton. It's a popular option for managing AC-4 jogging and the switching of motors in industrial automation systems. As it works seamlessly with IE3 efficiency-class motors, it's a reliable choice for achieving tip-top productivity. It also stands up to constant on-off toggling for up to 9,000 operations per hour, so it won't need to take any breaks. With a 400V AC contact voltage rating, this is an ideal option for high-power tasks. Installation is easily completed using the straightforward screw terminals, so there's no need for specialist tools.

Features & Benefits

• Compact dimensions of 68 (L) x 117 (D) x 45mm (W) means it fits in tight areas
• Mechanical lifespan up to 10 million operations ensures longevity
• Light 0.296kg weight doesn't add unnecessary load to your system

Is this device protected from debris?

This unit has an IP20 rating, which means it's touch-proof and protected from dust or debris greater than 12mm.

Can I use this contactor in harsh industrial conditions?

Yes. It functions in a broad operating temperature range between -25°C and +40°C, so is suitable for use in demanding environments.

Note

Eaton formerly known as Moeller
