277018 DILM17-10(RDC24), Eaton Contactor, 24 V dc Coil, 3-Pole, 17 A, 7.5 kW, 3NO, 400 V ac, Контактор

Eaton Contactor, Interference Immune, 17A Contact Current Rating - DILM Series - 277018 DILM17-10(RDC24)

Use this contactor from Eaton to switch circuits in your electric equipment on and off. It works by closing its contacts when the electromagnetic coil receives power, which energises the circuit. A maximum contact current rating of 17A makes it suitable for use in your high-power electrical applications. Thanks to the mechanical lifespan of 10,000,000 operations, you can rely on this device for long-lasting performance. A wide operating temperature range between -25°C and +60°C makes it safe to use in challenging environments.

Features & Benefits

• Complies with EN 60947-1 standard for immunity against electrical interference
• Finger-proof and back-of-hand-proof to help prevent electric hazards
• Built-in shock resistance to withstand demanding conditions
• Operating frequency of 5000 operations per hour for reliable daily use

How do I install this contactor in a control panel?

As it's compatible with the SmartWire-DT communication system, you can easily install this contactor in your control panel using a contactor module (774-0196)from the DIL-SWD SmartWire DT range. This communication system uses a multiconductor cable assembly, eliminating the need for multiple wire connections.

Note

Eaton formerly known as Moeller

DILM17-10(RDC24) Datasheet

Catalogue - Motor Starters & Special Purpose Ratings For The North American Market

Instruction Sheet - 277018 DILM17-10(RDC24)

Line Drawing - 277018 DILM17-10(RDC24)
