277119 DILM25-10(24V50HZ), Eaton Contactor, 24 V ac Coil, 3-Pole, 25 A, 11 kW, 3NO, 400 V ac, Контактор

Eaton Contactor, 250A Maximum Rated Breaking Capacity, 690V Rated Insulation Voltage - DILM Series - 277119 DILM25-10(24V50HZ)

Looking for a small but mighty powerhouse to get your three-phase motor working? This 3NO contactor from Eaton can handle the job. Thanks to a mechanical lifespan of 10 million cycles and the ability to handle up to 5000 operations per hour, this unit is a solid option that keeps your engines rolling for the long haul. Its 11kW power rating makes it ideal for medium-duty and heavy-duty systems used in a wide variety of settings, from factory automation to railway transportation.

Features & Benefits

• Compact dimensions of 45 (W) x 97 (L) x 85mm (H) ensure it fits easily into your setup
• Screw terminals mean installation is quick and connections are strong, even in vibrating systems
• Operates safely in demanding temperatures from -25°C to +60°C temperatures

How does this contactor work?

To turn your system on, this contactor has an internal coil that closes and completes the circuit when energised. When you cut the power, the coil loses that energy and springs back open, turning attached equipment off.

Note

Eaton formerly known as Moeller

Eaton DILM25-10(24V50HZ) Contactor Datasheet

Instruction Sheet - DILM(C)17

Catalogue - Motor Starter, Protector
