DBT72410, Sensata / Cynergy3 Sensata/Cynergy 3 Panel Mount Reed Relay, 24V dc Coil, SP-NC, 7000V dc Max, 2 A Max, 925Ω, Реле

HV Vacuum Encapsulated D Series

These high voltage PCB and panel mount reed relays have high isolation voltages of up to 15kV. Applications include test equipment and high voltage power supplies. All models are highly reliable and are of extremely good quality.

High power switching
Through hole PCB & panel mount or flying lead versions
15kV high isolation versions available
Tungsten contacts enable high voltage switching

Sensata Cynergy3 Reed Relay, SPNC, 1m - D Series - DBT72410

This Sensata Cynergy3 reed relay directs the electromagnet in a high-voltage reed switch. You can use it with switches of up to 24 volts on a direct current (DC), making it suitable for applications such as cardiac defibrillators, Triac trigger devices and high-voltage power supplies. The nylon studs connect to industry-standard circuits to create an airtight seal that stops dust from getting in. This unit offers low-power operation, making it an energy-efficient option.

Features & Benefits

• Mounts on a panel or printed circuit board (PCB) to suit your application
• High voltage connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals for flexible installation
• Low contact resistance so contact interface isn't disrupted or melted under high power

Can this relay withstand harsh environments?

The relay has a wide operating temperature range of -20°C to +70°C, so you can use it in demanding environments where extremes of cold and heat are likely.

How long will this relay last?

The relay has an approximate lifespan of 1,000,000 electrical cycles so you can be confident it's a long-lasting option.
