800F-11WE163, Allen Bradley Legend Holder for Use with 800F Series, Off

Legend Plate With Carrier

Legend plate carrier with snap in legend.
Choice of standard engraved texts.
30 x 40 mm legend carrier

Allen Bradley Legend Plate, Pre-Engraved With OFF, 40mm Height - 800F-11WE163

Looking for a way to make your panel easy to navigate? Clearly label your pilot devices with this legend plate from Rockwell Automation's Allen Bradley range. As the plate sits flush against the panel, it won't get in the way or snag on your cuffs as you go about your work. Crisp black lettering on a white background makes it easy to read at a glance, so it saves you time when seconds count. This unit is compatible with illuminated and non-illuminated push buttons, indicator lights, signalling lamps or selector switches from the 800F series, making it a versatile piece of kit.

Features & Benefits

• Compact dimensions of 40 (H) x 30mm (W) mean it fits comfortably onto your panel, even when space is tight
• Comes pre-engraved with the standard text OFF for convenience and clarity
• Supplied with a frame so you have everything you need to get labelling

Standards and Certifications

• UR
• UL
• CSA
• CCC
• CE

How do I fit this legend plate?

Installation couldn't be easier. Simply pop the frame into place behind your pilot device and use the handy snap-in method to fit the plate into the holder.

800F Series Pushbuttons & Indicators

The 800-F family of push-buttons, indicators, and accessories by Allen Bradley is expertly designed and manufactured to meet demanding performance specifications and reduce downtime by quickly and easily alerting personnel of hazards. Each component offers optimal durability and efficacy due to state-of-the-art solid modelling techniques and finite element analysis.

The Operators save you time and money as they can be quickly and easily installed. The 800-F range provides benefits such as: IP66 protection, CE/UL/CSA standards and CCC (Chinese standard) compliant, corrosion-resistant anodized plating finish, up to six circuits per operator, and single person panel installation. This family also adheres to industry standard 22mm hole fixing requirements.
The 800F range covers the following products:

• Illuminated/non-illuminated push-buttons and mushroom operators
• Pilot lights LED operated
• Selector, toggle, multi-function and key selector switches (2 and 3 positions)
• Custom laser engraving for pushbutton caps and diffusers
• Single turn potentiometer assembly
• Emergency stop push-buttons including the unique self-monitoring contact block
• Low front of panel profile
• Selection of silicone boots are available
• Plastic enclosures
• Metal operators offer ruggedness and durability
