277902 DILM65(230V50/60HZ), Eaton Contactor, 230 V ac Coil, 3-Pole, 65 A, 30 kW, 3NO, 400 V ac, Контактор

Eaton Contactor, 650A Maximum Breaking Capacity, 0.75 to 2.5mm² Wire Range - xStart Series - 277902 DILM65(230V50/60HZ)

Boot up your system in a flash with this Eaton contactor. It kickstarts motors rated up to 30kW, making it a go-to choice industrial actuation. As the unit opens and closes its circuits in between 8 and 18ms, it quickly responds to inputs to speed through machine control. Lining system connections up with the component's poles is no issue thanks to its handy labelled front plate. Secure screw-clamp terminals get a firm hold on wiring, cutting the risk of disconnection caused by vibration or movement. Contactors like this help to manage vehicle start-up systems and packaging lines.

• Completes up to 5,000 operations an hour to keep up with intense switching demands
• Impulse withstand voltage of 8kV AC means it can push through power surges
• Mechanical lifespan of around ten million cycles for long-lasting equipment control
• Works in operating temperatures between -25°C and +45°C, so it can handle tough industrial settings

Does this contactor come with built-in auxiliary contacts?

No, you should plug in a separate auxiliary contact block (493-0652) to connect the unit to a control device.

Note

Eaton formerly known as Moeller

Dimensional Drawing

DILM65(230V 50HZ) Datasheet

Instruction Sheet - 277902 DILM65(230V50/60HZ)

Catalogue - Product Range
