RS PRO Coaxial Cable, 100m, CT81 Coaxial, Unterminated, Кабель

RS PRO White Unterminated to Unterminated CT81 Coaxial Cable, 75 Ω, 7 mm OD, 100 m

Need to transmit cable or satellite TV over a long cable run? This CT81 coaxial cable from RS PRO is designed with the ideal electrical parameters for receiving digital TV via satellite or terrestrial transmissions. Cables of this kind are also used to transmit video and control cameras in CCTV systems.
The unit's copper strands offer excellent conductivity to transmit a clear signal and maintain image and audio quality. The cable is supplied unterminated so you can fit the conductors you need for your application.
The cable meets Euroclass ECA standards as a safe and effective copper network cable. Its polyvinyl chloride (PVC) sheath will help stop the spread in the event of a fire.

Features and Benefits

• Attenuation of 0.8 dB/10 m at 100 MHz
• Coaxial cable shape
• Capacitance of 55 pF/m
• Characteristic impedance of 75 Ω
• CT81 coaxial type
• Copper conductor material
• Solid conductor strand type
• Connector A is an unterminated connector type
• Connector B is an unterminated connector type
• L connector type
• PE (polyethylene) insulation material
• Length of 100 m
• One strand
• Outer diameter of 7 mm
• Reel length of 100 m
• White sheath colour
• Polyvinyl chloride (PVC) sheath material
• Strand size of 1 mm
• Euroclass Eca standards met
• Unterminated
