RS PRO 100A British Standard Fuse, A4, 550V ac, 94mm

RS PRO 100 A British Standard Fuse, A4, 550 V AC, 94 mm

Safeguard against short-circuits with this British Standard size 4A fuse from the RS PRO range that protects against high currents. This fuse has a gG rating so it's suitable for general use and will usually blow from two to five seconds at five times the rated current, and within 0.1 to 0.2 seconds at ten times the rated current.

The fuse is bolted so you can easily attach and mount it to your fuse holders. It has a current rating of 100 A with a voltage rating of 550 V AC. Thanks to its high rupturing capacity, if a short circuit occurs, it will stand up to the high pressure involved.

Part of the RS PRO series, this British standard fuse has been thoroughly tested by leading engineers. It's suitable for use in many domestic appliances and it's compliant with BS 88 and IEC 60269 specifications for British standard fuses.

Features and Benefits

• Body length of 58.5 mm
• Overall length of 110 mm
• Body height of 58.5 mm
• Body diameter of 21 mm
• Fixing centres at 94 mm
• Voltage rating of 550 V AC
• A4 fuse size
• Current rating of 100 A
• General purpose (gG) fuse
• High rupture capacity
• Bolted tags
• British Standard 88 and IEC 269 compliant

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS Pro Datasheet
