RS PRO Male SMC to Male SMC Coaxial Cable, 1m, RG174 Coaxial, Terminated, Кабель

5260320
Производитель: RS PRO
Цена за шт.
4843.80 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

RS PRO Black Coaxial Cable, 50 Ω

This RS PRO black coaxial cable is designed to send radio frequency (RF) signals over long distances while guaranteeing a secure and reliable connection. This model is built with reliable, industry-standard components and is very easy to install thanks to its plug-to-plug configuration. Cables such as these are widely used by IT personnel and electricians in telecommunications and wireless local-area network applications.
The black, brass-terminated cable has a wide range of applications including connecting radio transmitters to receivers using their antennas and serving TVs with satellite signals and Internet connections. The cable is designed with a MIL-STD-348A interface, which gives it good tolerance and stability and enhances its compatibility with other radio frequency systems.
This cable features highly effective Teflon insulation to meet ASTM D1457 and ASTM D1710 safety standards. These ratings also indicate the cable is fortified with mechanical strength and assure its insulation and shielding will protect the cable from damage and keep you safe.

Features and Benefits

• Operating temperature range of -40°C to +85°C
• Cable retention of 15 1bs MIN
• Centre contact made of beryllium copper
• Made from brass material
• Working voltage of 335 V
• Frequency of 1 GHz
• Three-year warranty
• Plug to plug

Техническая спецификация
pdfRS Pro Datasheet
Волновое сопротивление:
50 Ом
Встречающиеся стандарты:
MIL-STD-348A
Диапазон рабочих температур:
-40 → +85 °C
Длина:
Коаксиальный тип:
RG174
Материал изоляции:
PTFE
Материал проводника:
Латунь
Номинальное напряжение:
335 В
Обжатый/Необжатый:
Terminated
Рабочая температура - максимальная:
+85°C
Рабочая температура - минимальная:
-40°C
Разъем 1:
SMC
Разъем 1, Род:
Male
Разъем 2:
SMC
Разъем 2, Род:
Male
Цвет оболочки:
Черный
