2CDS253001R0321 S203-D32, ABB System Pro M Compact S200 MCB, 3P, 32A Curve D, 440V AC, 6 kA Breaking Capacity

ABB 3-Pole MCB, 440V AC Voltage Rating, 6kA Breaking Capacity - S200 Series - 2CDS253001R0321 S203-D32

Looking for a compact short-circuit protection solution for your electrical system? Choose this MCB from ABB. Its three-pole configuration makes it a practical choice for safeguarding three-phase systems from the effects of overvoltage and short circuits. Thanks to its thermoplastic housing, the unit is durable and can withstand mechanical impact, so you can rely on it for longevity in harsh environments. It's also finger-safe, with terminals that are located out of reach of your hands, to prevent accidental contact with live parts.

Features & Benefits

• Current rating of 32A suitable for high-current applications
• Compact dimensions of 88 (height) x 52.5 (width) x 69mm (depth) for use in setups with limited space
• Light weight of 375g so it doesn't put pressure on the mounting surface
• Compatible with both busbars and conductors for versatility

Applications

• Industrial fans
• Low-pressure and high-pressure compressors

What's the temperature tolerance range of this MCB?

This MCB can operate reliably within a temperature range of -25°C to +55°C, so it's suitable for use in harsh conditions.

Standards

BS EN 60898

Datasheet

Instruction Sheet - Miniature Circuit Breaker

Catalogue - Miniature Circuit-Breakers

End of life instructions S200, S200L, SZ200, SC200, S200M

Product Environmental Profile
