Norgren 3/2 Pneumatic Solenoid Valve - Solenoid/Spring G 1/2 V63 Series, V63D417A-A2000, Клапан

IMI Norgren Pneumatic Solenoid Valve, Internal Pilot, 4500L/m Flow Rate - V63 Series - V63D417A-A2000

Reliably control airflow with this pneumatic solenoid valve from IMI Norgren. Its 3/2-way function lets you control single-direction pneumatic systems and vent excess pressure. As the valve can handle operating pressures between 2 and 10 bar, you can adjust the airflow to suit your application. A nitrile rubber seal keeps water out to prevent actuator failure, while the aluminium housing is corrosion-resistant to further protect your device in damp conditions.

Features & Benefits

• Compact dimensions of 107 (L) x 65 (W) x 35mm (D) minimise bulk in your equipment
• Broad operating temperature range of -10°C and +50°C for use in demanding conditions
• Flow rate of 4200L/min suits industrial pneumatic systems

Applications

• Automation systems
• Construction facilities
• Manufacturing production

How do I mount this valve?

You can easily mount this valve to a DIN Rail or manifold system, so it's a convenient option.

How does this solenoid valve work?

This valve uses electromagnetic force to operate. As it's in a normally closed position, electricity passing through the solenoid coil generates a magnetic field that lifts a ferrous metal rod and moves the spool to open the valve. When the electricity is shut off, the spring actuator returns the valve to the NC position.

Data Sheet

V60 … V63 Series Valves Datasheet
