2CDS273001R0204 S203M-C20, ABB System Pro M Compact S200M MCB, 3P, 20A Curve C, 440V AC, 10 kA Breaking Capacity

ABB MCB, 10kA Breaking Capacity, 20A Current Rating - S200M Series - 2CDS273001R0204

Use this MCB from ABB to protect your industrial equipment from short-circuits and current overload. As it's a type-C unit, it can withstand between 5 and 10 times its rated current of 20A for safe use in demanding operations. For added durability, this component is resistant to shock and vibration. Mounting it is easy, as you can simply snap it onto a DIN rail without the need for any tools. Compact dimensions of 88 (height) x 52.5 (width) x 69mm (depth) make it a space-saving choice for busy setups or smaller consumer units.

Features & Benefits

• Colour-coded indicator window for simple status monitoring
• Ambient operating temperature range between -25°C and +55°C to withstand challenging environments
• Finger-safe terminals to prevent electrical hazards
• Electrical endurance of 20,000 cycles for lasting use

Applications

• Factory floors
• Lighting fixtures
• Mining and quarrying industries
• Data centres

What's meant by the breaking capacity of an MCB?

The breaking capacity is the maximum current an MCB can withstand without tripping. This unit has a breaking capacity of 10kA, making it suitable for use in high-power systems.

Standards

BS EN 60898

Datasheet - 2CDS273001R0204 S203M-C20

Brochure - Electrification Offering Guide

Catalogue - Miniature Circuit-Breakers

Product Environmental Profile
