RS PRO 82dB Panel Mount Fast Pulse Internal Piezo Buzzer, 39.5 x 28 x 25.4mm, 4V dc Min, 28V dc Max

RS PRO 82dB, Panel-mount Fast-pulse Internal Piezo Buzzer

These versatile internal piezo buzzers from RS PRO are an adaptable and energy-efficient choice. They offer a broad voltage range, high sound output and low power consumption in a space-saving package. As they work at temperatures from -30°C and +85°C, they're suited to demanding working conditions inside or out.

Operating between 4 V dc and 28 V dc and needing only a 5 mA supply current, these buzzers produce a clear fast-pulsing 82 dB tone. Their design is compact and they can be panel mounted, so installation is straightforward. The buzzers feature flying leads, which make them easy to connect to circuit boards.

These piezo buzzer components conform to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 electrostatic control standards and have been stringently tested as part of our RS PRO range. They have many uses, from automotive equipment to fire alarms.

Features and Benefits

• Piezo buzzer with a fast pulsed tone
• Panel mounting
• Minimum supply voltage of 4 V dc
• Maximum supply voltage of 28 V dc
• 82 dB sound level
• Internal drive
• Diameter of 28 mm
• Length of 39.5 mm
• Height of 25.4 mm
• Operating temperature range of -30°C to +85°C
• Supply current of 5 mA
• Minimum frequency of 3000 Hz
• Maximum frequency of 4 kHz
