RS PRO 92dB Panel Mount Continuous, Fast Pulse Internal Buzzer, 42.5 (Dia.) x 42.5mm, 6V dc Min, 28V dc Max

6221556
Производитель: RS PRO
Цена за шт.
5343.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

RS PRO 92dB, Panel Mount Continuous, Fast Pulse Internal Buzzer

For high-quality internal buzzers, look to the RS PRO range. These continuous, fast-pulse buzzers deliver a clear tone and come in a space-saving unit, meaning they're a versatile choice.

With an operating range of 6 V dc and 28 V dc, these buzzers are compatible with most consumer appliances. They draw a 29 mA supply current to produce a continuous and fast pulsing 92 dB tone, which is loud enough to cut through loud environmental noise. All of this comes in a compact, panel-mount design measuring 42.5 mm. The buzzer units also feature FASTON terminals, so wires can be easily connected and crimped onto them without the need to solder.

They conform to the ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards so they've been protected from harmful electrostatic discharges while being handled and packaged. You'll find buzzers such as these in devices such as microwaves and doorbells.

Features and Benefits

• Piezo buzzer with a continuous, fast pulsed tone
• Panel mounting
• Minimum supply voltage of 6 V DC
• Maximum supply voltage of 28 V DC
• 92 dB sound level
• Internal drive
• Diameter of 42.5 mm
• Height of 33 mm
• Operating temperature range of -30°C to +85°C
• Supply current of 29 mA
• Minimum frequency of 2300 Hz
• Maximum frequency of 3.3 kHz

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Техническая спецификация
pdfRS PRO Datasheet
pdfRS PRO Datasheet
Высота:
33мм
Диаметр:
42.5мм
Максимальная частота:
3.3кГц
Максимальное напряжение питания:
28В пост. тока
Минимальная частота:
2300Гц
Минимальное напряжение питания:
6В пост. тока
Рабочая температура - максимальная:
+85°C
Рабочая температура - минимальная:
-30°C
Размеры:
42.5 (диаметр) x 42.5мм
Тип монтажа:
Крепление на панель
Тип привода:
Внутренний
Тип сигнала:
Continuous, Fast Pulse
Ток питания:
29мА
Уровень звучания:
92дБ
