CS10.481, PULS DIMENSION C-Line Switch Mode DIN Rail Power Supply, 100 → 120V ac ac Input, 48V dc dc Output, 5A Output,, Блок питания

PULS DIN Rail Power Supply

The PULS DIMENSION C-Line series single-phase DIN-rail switch-mode power supply has an output voltage of 48VDC at 5A current. This cost-optimised power supply is specifically designed with uncompromised quality and reliability for high-performance. The auto-select input voltage rating ranging between 100VAC and 120VAC/200VAC and 240VAC. This power supply has a specified life expectancy of the electrolytic capacitor of 50,000 hours. It has high immunity to power surges as well as low electromagnetic emission
Note:
Power de-rating between 60°C and 70°C

Features and Benefits

Slim design
20% output power reserves up to 45°C continuously allowed
Wide range auto select input
High efficiency is up to 91.6%
Power rating is 240W
Ripple factor and noise is 100mVpp
Excellent partial load efficiency
Minimal inrush current surge
Easy fuse breaking due to high overload peak current
Large screw terminals
Operation temperature ranges between -25°C and 70°C

Applications

Industrial control
Office
Communication and instrumentation equipment

Certifications

IEC
UL approved
EN
SELV
EAC
GL
CE certified

C- Series DC Power Supply Instructions

Datasheet
