MEAN WELL Embedded Switch Mode Power Supply SMPS, SP-200-27, 27V dc, 7.5A, 202.5W, 1 Output, 120 → 370 V dc, 85, Источник питания

Mean Well Embedded Switch Mode Power Supply

The Mean Well SP-200 series 202.5W single output AC to DC embedded switch mode power supply has an output current rating of 7.5A at 27VDC. It has a universal input supply voltage rating from 85VAC to 264VAC and 120VDC to 370VDC.
Note:
Derate output 2% per °C above 50°C
Depth does not include terminal block

Features and Benefits

high-efficiency
Long life and high reliability
Built-in constant current limiting circuit, suitable for battery charging
Built-in fan with speed control
Remote ON-OFF control, SP-200 series (optional)
LED indicator for power on
Easy installation
Screw terminals
Adjustable output voltage
Short circuit
Overload
Overvoltage and over temperature protection

Certifications

EN 61000-3-2 (power factor correction)
EN 55022 class B (EMC)
EN 60950
UL 60950
EN55032 (CISPR32) class B
EN61000-4-2,3,4,5,6,8,11
ENV50204
EN55024
Criteria A

SP-200 Series specification sheet

Declaration Of Conformity
