1788172, Phoenix Contact UMSTBVK 2.5/ 8-G-5.08 Series DIN Rail Terminal Block, Screw Termination

UMSTBVK 2.5 DIN Rail Connector – Phoenix Contact

The UMSTBVK DIN rail connectors from Phoenix Contact are designed to be used with Phoenix's MSTB 2.5 range of terminal blocks. This connector will allow you to directly mount terminal blocks onto NS 32 or NS 35 DIN rails thanks to its universal footing. The terminal block itself is a screw connection method terminal block to give you maximum connection strength over time, 5.08mm pitch for total versatility and is rated at 12A with a nominal voltage of 320V.

UMSTBVK series are made from a durable green polyamide just like the MSTB series and thanks to the MSTB series being so popular, this DIN rail connector can be used world-wide thanks to its well-known connection technology.

Features and benefits:

• Strong screw connection method with tension sleeves


• Footing can attach to NS 32 and NS 35 DIN rails


• Green in colour to match the MSTB range


• Cross section of 2.5mm²

UMSTBVK 2.5 DIN rail connector - 1788172

The 1788172 from Phoenix contact is an 8-position connector that is designed to be mounted onto a DIN rail. Cables and wires are connected to this connector by screw connections on the front face of the device and the terminals contain tension sleeves so you'll never need to worry about a loose cable in the connector. This connector had a well-known connection principle that will allow you to use it worldwide and can be combined with Phoenix's brilliant range of MSTB 2,5.

The housing is green in colour and made from a strong polyamide material. Not to mention, this connector can be put on most standard DIN rails. (NS32 or NS35)

Features and benefits:

• The small nimble connector can fit on NS32 or NS35 DIN rails.


• Can be combined with Phoenix's range of MSTB 2,5.


• Nominal current of 12 A and a rated voltage of up to 320 V


• Cross-section of 2.5mm for maximum compatibility


• Wire installation is easy with a screw-connection method

Approvals

UL, CUL, CSA
