1777293, Phoenix Contact 5.08mm Pitch 3 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

6486040
Номер производителя: 1777293Производитель: Phoenix Contact
Цена за шт.
2289.30 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Phoenix Contact CLASSIC COMBICON SMSTB & FRONT-MSTB 5.08mm Terminal Block Plug Connectors

CLASSIC COMBICON SMSTB 2.5 & FRONT-MSTB 2.5 cable mount plug-in terminal block connectors, 5.08 mm pitch with a 0.2 - 2.5 mm2 screw connection.

Features and Benefits

• Well-known connection principle allows worldwide use
• Optimized for tight installation situations: operation and conductor connection from one direction
• Low temperature rise, thanks to maximum contact force
• Allows connection of two conductors
• Plug units with front screw connections (plug direction parallel to cable axis)
• RoHS compliant

Note

Manufacturer part numbers prefixed with 1874, 18262 and 18263 have a 45° wire entry (SMSTB 2,5 - ST), prefixed with 1971 have a 45° wire entry and a screw mounting flange (SMSTB 2,5 - STF), prefixed with 17772, 17773 and 17774 have a front screw connection and a horizontal wire entry (FRONT-MSTB - ST).

Phoenix Contact Pitch PCB Terminal Block, 5.08 mm - FRONT-MSTB 2,5/ 3-ST-5,08 - 1777293

To connect printed circuit boards (PCB) to wires, use this PCB terminal block from Phoenix Contact. Its compact design with three-way connections allows for use in tight spaces. To ensure easy installation in hard-to-reach areas, the operation and conductor connections are on the same side. Screw terminals let you quickly make secure connections without needing specialist tools.
This durable unit provides reliable signal transmission, as the tin contact surface provides optimum protection from oxidation and wear. To ensure versatility, it's designed to accommodate wire sizes ranging from 24 to 12 AWG (American Wire Gauge). The robust nylon construction and maximum contact force keep the temperature of your electrical components low during operation.
You'll find this connector used in a wide range of industrial and commercial applications, including renewable energy systems and automotive electronics.

• Current rating of 12 A
• Not fused
• Female gender
• Nylon material
• Cable mounting type
• Pitch of 5.08 mm
• Screw-down termination method
• Voltage rating of 320 V
• Weight of 8.9 g
• Overall dimensions of 27.2 (length) x 15.24 (width) x 14.9 mm (height)

Approvals

UL, CUL, CSA

Техническая спецификация
pdfDatasheet
pdfDimension Sheet - 1777293
pdfCatalogue - Terminal Block
Кол-во контактов:
3
Количество рядов:
1
Концевая заделка:
Винт
Материал:
PA (Insulate)
Номинал тока:
12A
Номинальное напряжение:
320 В
Ориентация корпуса:
Прямой
Серия:
FRONT-MSTB 2.5/ 2-ST-5.08
Тип монтажа:
Кабельное крепление
Тип съемного клеммного блока:
Plug
Цвет:
Зеленый
Шаг:
5.08мм
