52106230 & 53119030, Lapp SKINDICHT Series Grey Glass Fibre Reinforced, Polyamide Cable Gland, M25 Thread, IP55, Кабельный ввод

Lapp IP55 Metric Skintop KW-M 90° Elbow Cable Glands

From Lapp, this Skindicht KW-M series of cable glands are a space-saving solution to cable management. Their right angle orientation means they are ideal for when cables run parallel to a housing wall, or when a low installation height is required.

With a tough glass-filled polyamide construction, the cable glands are also light weight and offer a degree of environmental protection.

Supplied with a lock nut, the Skindicht KW-M series of cable glands assure a quick and secure fitting in any position.

Features and Benefits

• Right Angle Orientation
• Space and Weight Saving Design
• Decrease in Installation Height
• IP55 Protected
• Operating temperature range from -20°C to +100°C

Applications

These elbow cable glands present a versatile cable management solution in;
• Control Cabinet Manufacturing
• Light and Sound Applications
• Ideal for Thin Cable Diameters

Environment

These cable glands seal to IP55, which means they offer good protection again dust and particle ingress, and a moderate protection against liquid. This means they are suitable for most indoor applications.

Features and Benefits

Decrease in installation height
Operating temperature range from -20°C to +100°C
Various thread sizes available from M16 to M32

Typical Applications

Light and sound applications
Control cabinet manufacturing

Standards

EN50262

Supplied with

Lock Nut

LAPP Cable Gland, 16mm Thread Length, UV-Resistant - SKINDICHT Series - 52106230+53119030

Shield your connections from the elements with this M25 cable gland from LAPP. It secures your lead to the enclosure, preventing it from accidentally coming off due to vibration and exposing your connection. Thanks to an angled design, it's the right choice for changing your wiring path. The unit's glass fibre-reinforced construction gives it durability, as it handles wear and impact without breaking a sweat.

Features & Benefits

• Comes with a locknut for a tight hold on the join
• Five in a bag to cover multiple jobs
• Withstands between -20°C and +80°C of operating temperature, making it safe for use in challenging settings

Applications

• Machine building
• HVAC systems
• Process and packaging equipment

Is this cable gland dust-resistant?

Yes. This component's IP55 rating shows it's protected from limited amounts of dust, as well as low-pressure water jets.

LAPP_PRO998_Datasheet

Datasheet

Cable Gland Selection Chart
