2866611, Phoenix Contact 85 → 264 V ac, 100 → 350V dc Input DIN Rail Uninterruptible Power Supply (120W), TRIO-UPS, ИБП

Phoenix Contact TRIO-UPS

The Phoenix Contact range of TRIO-UPS is a compact range of DC uninterruptible power supplies.
The UPS will switch to battery operation with no interruption if there is a mains power failure. This provides the protection and reliability of your electrical loads. When the mains power is restored the UPS will switch to normal operation.

Features and Benefits

• The power supply and electronic switchover in the same housing means that you save space
• Large selection of VRLA energy storage systems means long buffer times
• Push-in connection means they are easy to install
• Wide temperature range
• Use anywhere in the world
• No power supply is not an issue as you can start up using the energy that is stored
• Adapt the behaviour to your application by using UPS-CONF software

Phoenix Contact Uninterruptible Power Supply, 24V DC Output, 130mm Length - TRIO-UPS/1AC/24DC/ 5 - 2866611

Transition smoothly to battery power in the event of a mains failure with this UPS (uninterruptible power supply) from Phoenix Contact. It automatically switches to battery operation with no interruption and returns to normal operation when mains power has been restored.
The unit's integrated energy storage comprises a power supply and electronic switchover in the same housing, which saves space in your control cabinet. Its AGM (absorbent glass mat) batteryis maintenance-free and offers particularly long buffer times, thanks to its integrated storage system. An integrated USB (universal serial bus) interface lets you link the UPS to higher-level controllers for the reliable and safe shutdown of connected industrial computers.
This UPS can be easily retrofitted into existing systems. As it's universal, it can be used anywhere in the world. It meets EN 50121-4 (European Norm) electromagnetic compatibility standards for signalling and telecommunications equipment in railway applications.

• Wide operating temperature range of -25°C to +70°C for reliable use in challenging environments
• IP20 (ingress protection) rated enclosure that's safely protected from touch and large dirt particles
• Buffer module type for minimal maintenance needs
• Complies with DIN VDE 0100-410 standards for protection against electric shocks

Datasheet 2866611
