2315146, Phoenix Contact VIP-3 Series 37-Contact Male Interface Module, D-sub Connector, DIN Rail, 2A, Модуль

Phoenix Contact Interface Module, M3 Screw Thread, 8mm Wire Stripping Length - VIP-3/SC/D37SUB/M - 2315146

Make linking devices to your electrical setup a breeze with this interface module from Phoenix Contact. Its plug-and-play design, with a 1:1 connection, makes signal distribution glitch-free. The 3-row design means 37 contacts are available, so you can run lots of circuits at once, boosting your workflow. The unit's secure D-sub connector is just the thing for maintaining reliable signal transmission in challenging settings. That's because it offers high integrity between conductors while shielding against EMI, which supports uninterrupted performance.
Robust polyamide housing material ensures the module handles mechanical stress and corrosion to deliver a long service life. Compact dimensions of 62 (H) x 72.7 (W) x 69mm (D) mean it fits neatly into tight areas in your infrastructure. DIN-rail mounting makes installation snappy and straightforward without specialist tools.

Features & Benefits

• 1.2kV surge protection safeguards against hazardous over-voltages
• 24 to 12AWG for wide compatibility with commonly used wires
• UL 94-V0 rating means it's self-extinguishing in under 10 seconds in the event of a fire
• Performs reliably in a temperature range between -20°C and +50°C to suit harsh environments

VIP-3/SC/D37SUB/M VARIOFACE Module Data Sheet

Line Drawing - 2315146
