RS PRO Brass Female Pneumatic Quick Connect Coupling, G 1/4 Female Threaded, Муфта

RS PRO Pneumatic Quick Connect Coupling Brass 1/4 in Threaded

This female quick-connect pneumatic coupling lets you attach hose, piping and tubing when used with a male coupling connector. It's hardwearing and suitable for a range of industrial applications, including airline and automotive uses.

There's a threaded connection, which comes in a quarter-inch thread size and is of a standard G type. It features a quick-connect system to create a fast connection but also allows for a single shut off. Easily operable with one hand, you'll get the job done quicker. It's interchangeable with PCL Airflow, CEJN 295 and Rectus 19 series parts.
The coupling's body is made of nickel-plated brass that ensures resistance to corrosion and wear. There's also a nitrile rubber seal that's resistant to liquids, including oils, water, gasoline and some hydraulic fluids. This coupling has a maximum operating pressure of 35 bars and functions at temperatures ranging from -20°C to +100°C.

Features and Benefits

• Pneumatic quick-connect coupling
• Connection standard of PLC 60, Rectus 19
• Operating temperature of -20°C to +100°C
• Maximum operating pressure of 35 bar
• Threaded connection of G 1/4 Female
• Manufacturer series 19
• Nickel-plated brass couple body
• Nitrile rubber seal to resist corrosion
• Thread standard of G
• Female coupling
• Made from brass
• Plated with nickel
• Interchangeable with PCL Airflow, CEJN 295 and Rectus 19 series parts
