RS PRO Brass Male Pneumatic Quick Connect Coupling, G 1/4 Male Threaded, Муфта

RS PRO Pneumatic Quick Connect Coupling Brass 1/4 in Threaded

The RS PRO pneumatic quick-connect coupling brass lets you attach tubes, pipes and hoses together. You'll find it in industrial applications that depend on high-flow performance and minimal pressure loss, such as dental equipment.
This Series 23 coupling is a threaded connection. It comes in a G-standard quarter-inch thread size, compliant with the following standard connectors: CEJN 310, Dynaquip DC3, ISO 6150B, Rectus 23 & 24 and US MIL C4109. The quick-connect feature creates a fast join and the single shut off works to standard type C9000 ISO P6 Series.

Made of nickel-plated brass, the couple body and sleeve is corrosion-resistant, providing extra protection. It has a nitrile rubber seal to protect against contaminations from liquids including oil, water and gasoline. The coupling works between -20°C and +100°C and has a maximum operating pressure of 35 bars.

Features and Benefits

• Pneumatic quick-connect male coupling
• Manufacturer Series 3
• G-standard quarter-inch thread size
• Tested to work at temperatures between -20°C and +100°C
• Maximum operating pressure of 35 bar
• Nitrile rubber seal protects against contamination
• Nickel-plated brass body
• Nickel-plated steel sleeve
• Connection compliant with CEJN 310, Dynaquip DC3, ISO 6150B, Rectus 23 & 24 and US MIL C4109 standards for safety and quality

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS Pro Datasheet
