RS PRO Brass Male Pneumatic Quick Connect Coupling, G 1/2 Male Threaded, Муфта

RS PRO Pneumatic Quick Connect Coupling Brass 1/2 in Threaded

This pneumatic connector from RS PRO combines very high flow capacity with low pressure drop, making it an accurate and reliable component for pneumatic systems. It's suitable for use with compressed air in heavy tool applications.

The pneumatic quick-connect coupling is fitted with a BSP Parallel G 1/2 in male thread. It's interchangeable with CEJN 410, Rectus 27 and TST 410 type connectors. The nickel-plated brass construction resists corrosion, while a nitrile rubber seal guards against leakage to ensure maximum efficiency. As a single shut-off type connector, it also allows one-handed operation.

The connector will operate up to a maximum temperature of +100˚C and down to a minimum temperature of -20˚C. It has a maximum operating pressure of 35 bar. This type of connector is commonly used in applications such as large air tool connections, mains supply outlets and stamping equipment.

Features and Benefits

• Pneumatic quick connect coupling
• G thread standard
• 1/2 in threaded connection
• Male thread
• Male coupling
• Maximum operating pressure 35 bar
• Maximum operating temperature of +100˚C
• Minimum operating temperature of -20˚C
• Nickel-plated finish resists corrosion
• Nitrile rubber seal prevents leakage
• Manufacturer series 27
• Conforms to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards
• RoHS (Restriction of Hazardous Substances) compliant

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS Pro Datasheet
