87832-1208, Molex Milli-Grid Series Straight Surface Mount PCB Header, 12 Contact(s), 2.0mm Pitch, 2 Row(s), Shrouded, Штыревой разъем

Vertical SMT Shrouded Headers, 87832 Series

Mates with 51110 Series receptacles typical stock number 670-3588
Contact Plating 0.38μm Gold (unless otherwise stated), termination plating Tin

Molex 2.0 mm Milli-Grid Interconnection System

The Milli-Grid connector system is a high density connector system based on a 2 x 2 mm grid pattern offering design flexibility for board to board and cable to board applications. The Milli-Grid family of connectors consists of shrouded and unshrouded headers, single and dual row receptacles, connector housings and crimp terminals

Mgrid Shrouded Header Drawing

Line Drawing
